A cloud administrator is deploying a new software-defined data center (SDDC) in VMware Cloud on AWS. Long-term planning indicates that a minimum of 30 hosts are required.
What is a valid management network CIDR based on the requirements?
A valid management network CIDR based on the requirements is 10.1.0.0/20, as this provides a range of 4096 IP addresses, which is more than enough for 30 hosts. A /23 CIDR only provides 512 IP addresses, which is not enough for 30 hosts, while a /24 CIDR provides 256 IP addresses and a /16 CIDR provides 65,536 IP addresses, which is more than is needed for the 30 hosts.
https://blogs.vmware.com/cloud/2019/10/03/selecting-ip-subnets-sddc/
What must a cloud administrator configure in order to allow a company's on-premises data center to access the VMware Cloud on AWS vCenter Server.
When configuring Hybrid Linked Mode, what is the maximum supported latency between an on-premises environment and a VMware Cloud on AWS software-defined data center (SDDC)?
Hybrid Linked Mode can tolerate a time skew of up to ten minutes between the on-premises data center and the cloud SDDC. The maximum latency between your cloud SDDC and on-premises data center cannot exceed 100 msec roundtrip.
A cloud administrator is asked to validate a proposed internetworking design that will provide connectivity to a VMware Cloud on AWS environment from multiple company locations.
The following requirements must be met:
* Connectivity to the VMware Cloud on AWS environment must support high-throughput data transfer.
* Connectivity to the VMware Cloud on AWS environment must NOT have a single point of failure.
* Any network traffic between on-premises company locations must be sent over a private IP address space.
Which design decisions should be made to meet these network connectivity requirements?
Option C is the best design decision that meets the network connectivity requirements. Configuring a Direct Connect from headquarters to VMware Cloud on AWS with a private VIF will ensure high-throughput data transfer and eliminate the single point of failure. To ensure that all network traffic between on-premises company locations is sent over a private IP address space, a route-based IPsec VPN tunnel should be configured as a secondary method of connectivity from headquarters to VMware Cloud on AWS, taking care to enable the 'Use VPN as Backup to Direct Connect' option. Finally, dual, redundant, route-based IPsec VPN connections should be configured from each regional office to VMware Cloud on AWS.
A cloud administrator wants to enable administrator wants to enable Enterprise Federation to the Cloud Services Portal in order to be able to authenticate with the on-premises Active Directory. The Administrator Already deployed the on-premises VMware Workspace One Access Connector. Through which port does the Cloud Service Portal communicate with Workspace ONE Access Connector?
