In this exercise, you will create a UiPath automation that performs the steps below.
To achieve this, you will use the REFrameWork as the starting template and follow the UiPath development best practices.
Here are the steps performed by the Robot:
1. Log in to https://www.acme-test.com.
2. On the landing page, Dashboard, click or hover over the Vendors menu item and then click on Search for Vendor. Click on Display All Vendors. Scrape the data from the whole table isplayed. The resulting datatable will be used as the input data for the process. Navigate back to the dashboard.
Note: Navigation can be achieved in multiple ways by the robot - choose whichever you find best.
3. For each Tax ID:
- Navigate to Vendors - Search page (click or hover over the Vendors menu item and then click on Search for Vendor);
- Type the Tax ID into the Vendor Tax ID field;
- Click on Search;
- Extract the values for the Vendor, City and Country and compare them with the values from the previously extracted table from the Display All Vendors page (check for EXACT match for all fields!);
- If the values are not matching, this should be categorized as a Business Rule Exception;
- If the City does NOT belong to the group {""Paris"", ""Bucuresti"", ""Moscow"", ""Stuttgart"", ""Koln""}, this should be categorized as the second Business Rule Exception. We can only process requests from these cities. Check the City value extracted after the individual Tax ID search;
- If no Business Rule Exception, Append the resulting datatable from each page into an Excel worksheet;
you shouldn't worry about the headers and format of the output file.
Constraints to follow in the development, using the REFrameWork:
1. TransactionItem datatype should be a DataRow. The process should recover and retry 2 times in case of errors in navigation between the Vendor Search and Vendor Search Results pages. One transaction is the action of navigating to the Vendor Search page, searching for the TaxID and scraping the values from the resulting one row table. (Similar to ACME Process 5 from the UiPath Academy).
2. Create a separate workflow file for the Login to ACME. File input arguments: URL ; Username ; Password .
3. Create a separate workflow file for closing ACME.
4. Add the ACME_URL and ACME_Credential to the Excel Config file.
5. Populate InitAllApplications.xaml from the Framework folder with Invoking the Login to ACME and navigation to the Work Items.
6. Populate CloseAllApplications.xaml from the Framework folder with Invoking the Close ACME.
7. Populate KillAllProcesses.xaml from the Framework folder with killing the process used.
8. Populate the Process.xaml file with the following actions: Navigation, Searching for TaxID, Scraping, Checking if the values match, Checking for the correct City, Appending to Excel.
Important Note: Don't use external file references outside of the project folder (including Orchestrator Assets). Place all the used files within the project folder, zip that folder and upload it to the UiPath Certification Platform.
Zip ALL the used workflow files AND the output Excel file. Then upload the .zip file to the UiPath Certification Platform.
A developer has configured the Activity Project Settings for UI automation and a Click activity as shown below. The required selector does not exist. What Timeout value will be used by the robot once executed in Run Mode?
Please find the properties of the Click activity below.
Settings changed in Project Settings take effect if the corresponding property is left blank in the activity. If in the same project an activity has the Timeout property manually set (even if the value 30000 milliseconds is the same as the default one), then the value set in the property panel overwrites any other value configured in the Activity Project Settings window.
UiPath Documentation
Exam Topic:Describe how to use and configure Activity Project Settings and Libraries
What will be the value of isEven variable at the breakpoint, once the robot runs in Debug mode?
The default value of a Boolean variable isFalse. As 10 mod 2 = 0 is True, robot will assign True to the isEven variable. However, the processing is pausedbeforeexecuting the activity with a breakpoint. So at the moment of the breakpoint, the value of isEven will still beFalse, and will be changed once Continue or Step Into button is pressed.
UiPath Documentation
Exam Topic:Examine and describe the activities and/or features used to troubleshoot, debug, and modify processes
Based on the configuration shown in the exhibit, what is the result of the execution of these activities if the target element does not exist at runtime?
Which one of the statements below regarding the GetAppCredentials workflow included in UiPath Robotic Enterprise Framework is true?
Options are :
