What is the simple difference between a main distribution framework (MOF) closet and an intermediate distribution framework (IDF) closet?
In network design, the Main Distribution Frame (MDF) and Intermediate Distribution Frame (IDF) are critical components of the network infrastructure. The MDF is the primary hub of the network, often where services from outside the campus or building enter and get distributed. It acts as a central point for network distribution. On the other hand, IDFs are secondary hubs situated throughout the building or campus, extending connectivity provided by the MDF to various endpoints or areas within the building. The simple difference between them lies in their roles within the network infrastructure: the MDF serves as the main point of network ingress and egress, while IDFs are used to further distribute the network to specific locations or floors within the building.
A global furniture retail company called 'No-Stair Inc.' requests you design their new WLAN infrastructure for a global footprint. Each location of No-Stair Inc.' has a similar layout: three small manager offices, a warehouse, and a 'retail' are
a. The 'retail' area and the warehouse together amount to 95% of the location. The IT department of the company Is minimally engaged In their LAN refresh so the CTO of the company has shared the information below
Current WLAN Infrastructure Is based on the 802.1 In "WlF14Less" access-points series (both model 2013-INT (2.4 only Internal antenna) and model 2019-EXT (dual-band external antenna only)). These AP models are standalone without any centralized management. Last year 'No-Stair InC ran a project called secure. It' ensuring that all needed network security was Implemented to be fully compliant with their security standards. During this project, they also upgraded the AAA infrastructure to handle the Increased AAA requests. No additional Wi-Fi or security requirements are listed for this WLAN refresh, which means that 'No-Stair Inc.' will continue to use bridged SSIDs. with local breakout into different VLANs.
The CTO of No-Stair Inc.' understands the need for you to ask additional questions to deliver the design The questions may be sent in written form and will be answered within two weeks.
Which additional question is correct in order to collect needed information for the WLAN design?
An RF (Radio Frequency) survey report is crucial for WLAN design as it provides detailed information about the current wireless environment, including signal strengths, interference sources, coverage gaps, and the effectiveness of the existing WLAN infrastructure. For a company like 'No-Stair Inc.' that is planning to refresh its WLAN across a global footprint, understanding the current RF conditions in each location is essential. This information helps in designing a WLAN infrastructure that can meet the specific needs of different areas within the locations, such as the retail area and warehouse, ensuring optimal coverage, performance, and user experience. An RF survey report would allow the designer to make informed decisions regarding the placement of new access points, the selection of appropriate antennas, and the configuration of WLAN parameters to improve coverage and capacity while minimizing interference.
ACME retail has 38 locations spread out across Ave US states and two provinces in Canad
a. They are looking to grow 20% over the next two years. They have an HO with a staff of 200 employees. The organization has eight Regional Managers and two VPs who work from home and the road. Stores typically have 17 employees on average per location.
The two warehouses have a remote loading system and 20 employees each to load the trucks and fulfill the online orders. The warehouse has 40-foot ceilings and large metal racks to store inventory. The main location is 240K sq ft (22300 st) m) and the Canadian warehouse Is 130K sq ft (12100 sq ml. The forkllfts on the loading docks are equipped with a wireless tablet on board.
A typical store Is reportedly about 60.000 sq ft (5575 sqm) and smaller stores are planned at 25.000 sq ft '2320 sq mi. The locations need to expand the abilities to vendors that need to add setup displays or Interactive kiosks in the stores. The current Infrastructure was installed In 2015 and used wireless N technology in a coverage model. The wiring is CatS. and they are unsure of the fiber connections. The inventory is all placed on the floor when it is delivered to the local store.
Inventory control is handled through Zebra barcode scanners, and they have had a lot of issues in getting signals throughout the stores and this makes monthly inventory difficult. The organization has a small help desk to troubleshoot issues that happen at the retail locations and PC support for the office. The company is looking to upgrade away from the current pbx system later this year. With the need to grow and cut costs, they are interested in moving the data to the cloud but need to get almost real-time inventory control for the online service to function.
The network has all been wired over the last ten years, but with the new systems being all wireless, they have seen the trend to offer wireless to all the vendors for their needs but also would like to allow employees, guests, and contractors all to use it. With the new IT director starting next week, the project has been set by the CTO of the company. The marketing group has asked how they can interact with the customers and get more info, while the IT support desk needs to cut staff in halt.
The. office has an MDF and two IDFs located on floors one and two. The HOF is in the basement, and you have multiple WAN circuits for the HO links. Each store has a local handoff from the cable company (ethernet) In the middle of the store in the office, so distance for the wiring is not an issue.
The customer has budget concerns but does want something that could last 7+ years.
What are two primary concerns of the Stakeholder' (Select two.)
For the stakeholders at ACME Retail, the primary concerns include the cost of the solution and ensuring that the solution is future-proof. Given the company's budget concerns, it is crucial that the chosen network infrastructure offers a good return on investment and aligns with their financial constraints. At the same time, considering the company's growth plans and the rapid evolution of technology, the solution must be scalable and adaptable to future needs. This involves selecting networking equipment and technologies that can support emerging trends, such as increased wireless device usage, cloud computing, and advanced security requirements, without necessitating frequent, costly upgrades. Balancing these concerns will help ACME Retail achieve its operational goals while positioning itself for sustainable growth and innovation.
which documentation resources con be used for finding validated information on Aruba products that assist the architect in building the solution design? (Select three.)
When seeking validated information on Aruba products to assist in building a solution design, the most reliable resources include configuration guides (Option B), datasheets (Option C), and validated Solution Guides (Option F). Configuration guides provide detailed instructions and best practices for setting up and optimizing Aruba products, ensuring their proper integration into the network infrastructure. Datasheets offer concise overviews of product specifications, features, and capabilities, allowing architects to assess product suitability for specific requirements. Validated Solution Guides compile comprehensive information on deploying Aruba solutions in various scenarios, ensuring that the solution design is based on proven methodologies and recommended practices, thereby enhancing the reliability and performance of the network solution.
A large multinational financial institution has contracted you to design a new full-stack wired and wireless network for their new 6-story regional office building. The bottom two floors of this facility will be retail space for a large banking branch. The upper floors will be carpeted office space for corporate users, each floor being approximately 100.000 sq ft (9290 sqm). Data centers are all off site and will be out of scope for this project. The customer is underserved by its existing L2-based network infrastructure and would like to take advantage of modern best practices in the new design. The network should be fully resilient and fault-tolerant, with dynamic segmentation at the edge.
The retail space will include public guest Wi-Fi access. Retail associates will have corporate tablets for customer service, and there will be a mix of wired and wireless devices throughout the retail floors. The corporate users will primarily use wireless for connectivity, but several wired clients, printers, and hard VoIP phones will be in use.
The customer is also planning on renovating the corporate office space in order to take advantage of "smart office' technology. These improvements will drive blue-dot wayfinding. presence analytics, and other location-based services
The client is looking to utilize lower-cost Aruba OS-CX switches in their wiring closets. They calculate that each closet will need a stack or qty 6 POE (AT) and qty 0 Gigabit Ethernet switches stacked with low-cost OACs.
Which series switch should you recommend?
The Aruba CX 6300F series is a suitable recommendation for the described scenario due to its performance, PoE capabilities, and cost-effectiveness for wiring closet deployments. The CX 6300F series offers the flexibility and scalability needed for modern network environments, supporting both wired and wireless connectivity demands. It provides advanced features such as stackability, high-density PoE options, and the capability to support dynamic segmentation, which is essential for separating and securing different types of network traffic, such as corporate data and guest Wi-Fi access. This series is designed to meet the needs of a full-stack wired and wireless network in a large, multi-story office building, providing the necessary infrastructure for both current and future network requirements.
