Question No. 1

Refer to the exhibit.

What is the result of the Ansible task?

AIt configures a Cisco IOS XR router with BGP AS65000 with two neighbors and redistributes OSPF into BGP.

BIt validates the BGP configuration on a Cisco IOS XR router, but it is a read-only module and cannot modify the configuration on the router.

CIt validates the BGP configuration on a Cisco IOS XE router, but it is a check mode-only network module and cannot modify the configuration on the router.

DIt configures a Cisco IOS router with BGP on AS500 and redistributes OSPF into BGP.

Show Answer

Correct Answer: A

https://docs.ansible.com/ansible/latest/modules/iosxr_bgp_module.html

Question No. 2

An engineer wants to replace the BLOCK_BAD ACL on the Cisco IOS XE router with this new content. The engineer wants to use RESTCONF for this and constructs a PUT request to the resource/restconf/data/native/ip/access-list/Cisco-IOS-XE-acl:extended=BLOCK_BAD. What must the body look like to achieve the Cisco IOS XE configuration?

Desired configutation:

ip access-list extended BLOCK_BAD

permit ip any host 192.168.20.1

deny ip any any

A)

B)

C)

D)

AOption A

BOption B

COption C

DOption D

Show Answer

Correct Answer: D

Question No. 3

Refer to the exhibit.

What is the effect of the script on the device?

AAll interfaces except GigabitEthernet2 are reset to their default configurations.

BIt replaces the entire configuration for GigabitEthernet2 on the device using RESTCONF.

CIt merges the new configuration with the existing configuration on the device using RESTCONF.

DIt compares the configuration to the device. If it matches, the device sends back an HTTP 204 status code.

Show Answer

Correct Answer: C

Question No. 4

What is a key feature of YANG?

Ause identification

Berror prediction

CJAVA compatibility

Dreusable types and groupings

Show Answer

Correct Answer: D

https://www.cisco.com/c/en/us/td/docs/optical/ncs1000/60x/b_Datamodels_cg_ncs1000/ b_Datamodels_cg_ncs1000_chapter_00.html

Question No. 5

Refer to the exhibit.

An engineer updated the skeleton template. How can a device be entered into the YANG Model?

AModify the device instance of the device by referencing the acl_lab variable from our YANG model.

BDeploy a service instance that configures a VLAN of all of the devices present in Cisco NSO.

CDeploy a service instance that configures a VLAN of a list of devices referenced to the service YANG model.

DModify the device instance by referencing the device variable from our YANG model.

Show Answer

Correct Answer: D
